Finex - Air Swept Mill

Finex - Air Swept Mill

The infeed material is fed into the air stream at the mill inlet in a consistent metered fashion. The beater plates impact and reduce the size of the largest particles and distribute the material around the periphery of the grinding zone where product is ground against the liner by the hammers which are mounted on the beater plates. The beater plates rotate at between 1,600 and 4,000 rpm with tip speed velocities ranging from 19,500 to 34,000 feet per minute to achieve specific particle size distribution output. The classifier plate separates the finely ground product for exit through the discharge outlet while returning oversize material back to the mill inlet through the recycle housing/PJDC Dust Collector.

Features

• Dust Free Operation: Negative air pressure design keeps dust out of the air to eliminate health and plant hazards while resulting in clean conditions around the machine.
• Economy of Operation: The basic efficiency of the ASP design delivers an exceptional ratio of product yield to power consumption, processing time and related production costs.
• Ease of Maintenance: The Finex USP is undoubtedly the easiest fine grinder on the market to clean, to change out wear parts, or to service the drive and bearings.
